FishMate - Submersible Pumps
|
|
|  With an easy-to-clean strainer filter, this high-efficiency pump maintains a clean pond on low-running costs.
A single control knob adjusts flow to fountain, waterfall and filter. Four fountain options are available. Designed for durability, choose the model that best suits your pond's needs.
- Single control knob adjusts flow to fountain and waterfall/filter
- Ceramic shaft bearings and superior rotor design for long service life
- Fully encapsulated electrical parts for safety
- High efficiency pump turbine for low running costs
- Strainer filter less prone to blockage and easier to clean than conventional foam filters
|
FISH MATE Pump Model
|
600
|
800
|
1000
|
|
Maximum Flow Rate
|
580 GPH
|
790 GPH
|
1000 GPH
|
|
Maximum Head
|
6' 9"
|
6' 9"
|
7' 2"
|
|
Power Consumption (Wattage)
|
40W
|
42W
|
44W
|
|
Power Cable Length
|
24'
|
24'
|
24'
|
|
Dimensions (excluding flow valve)
|
L x W x H = 7-3/4" x 5-3/4" x 4"
|
| Outlet Size |
1" OD (Uses 1" ID tubing) |
| | Item # | Description | Price | Click To Order |
|---|
| AN-247 | FishMate Model 600 Submersible Pump | $ 80.00 |  | | AN-248 | FishMate Model 800 Submersible Pump | $ 99.00 | | | AN-249 | FishMate Model 1000 Submersible Pump | $ 120.00 | |
|
|
With an easy-to-clean strainer filter, this high-efficiency pump maintains a clean pond on low-running costs.
A single control knob adjusts flow to fountain, waterfall and filter. Four fountain options are included: Tiered, Column, Bell, and Plume. Designed for durability, choose the model that best suits your pond's needs.
- Single control knob adjusts flow to fountain and waterfall/filter
- Ceramic shaft bearings and superior rotor design for long service life
- Fully encapsulated electrical parts for safety
- High efficiency pump turbine for low running costs
- Strainer filter less prone to blockage and easier to clean than conventional foam filters
- Includes Pump, Diverer Valve and 4 Fountain heads: Tiered, Column, Bell and Standard plume
|
FISH MATE Pump Model
|
1500
| 2000 |
2500 |
|
Maximum Flow Rate
|
1600 GPH
|
2000 GPH
|
2400 GPH |
|
Maximum Head
|
15' 0"
|
15' 0"
|
15' 4" |
|
Power Consumption (Wattage)
|
90 W
|
95 W
|
110 W |
|
Power Cable Length
|
24'
|
24'
|
24' |
|
Dimensions (excluding flow valve)
|
L x W x H = 9-3/4" x 6-3/4" x 5-1/4"
|
| Outlet Size |
3/4", 1" and 1-1/4" (Uses 3/4", 1" and 1-1/4" ID tubing) |
| | Item # | Description | Price | Click To Order |
|---|
| AN-277 | FishMate Model 1500 Submersible Pump | $ 199.00 | | | AN-278 | FishMate Model 2000 Submersible Pump | $ 219.00 | | | AN-279 | FishMate Model 2500 Submersible Pump | $ 229.00 | |
|
|  With an easy-to-clean strainer filter, this high-efficiency pump maintains a clean pond on low-running costs.
A single control knob adjusts flow to fountain, waterfall and filter. Three fountain options are included: Tiered, Aerated Plume and Plume. Designed for durability, choose the model that best suits your pond's needs.
- Single control knob adjusts flow to fountain and waterfall/filter
- Ceramic shaft bearings and superior rotor design for long service life
- Fully encapsulated electrical parts for safety
- High efficiency pump turbine for low running costs
- Strainer filter less prone to blockage and easier to clean than conventional foam filters
- Includes Pump, Diverer Valve and 3 Fountain heads: Tiered, Aerated Plume and Standard plume
|
FISH MATE Pump Model
|
4000
| 5500 |
|
Maximum Flow Rate
|
4200 GPH
|
5350 GPH
|
|
Maximum Head
|
23' 3"
|
28' 10"
|
|
Power Consumption (Wattage)
|
295W
|
445W
|
|
Power Cable Length
|
33'
|
33'
|
|
Dimensions (excluding flow valve)
|
L x W x H = 16.75" x 7.5" x 7.75"
|
| Outlet Size |
3/4", 1" and 1-1/4" (Uses 3/4", 1", 1-1/4" and 1-1/2" ID tubing)
(We recommend not using less than 1-1/4") |
 | | Item # | Description | Price | Click To Order |
|---|
| AN-326 | FishMate Model 4000 Submersible Pump | $ 354.20 |  | | AN-327 | FishMate Model 5500 Submersible Pump | $ 396.50 | |
|
|  Replacement Parts for the Fish-Mate / Ani-Mate brand pumps.
- Filter Sponges
- Pump Cage/Casing
- Fountain Sets
Picture shows Replacement Casing for the 600 / 800 / 1000 pump | | Item # | Description | Price | Click To Order |
|---|
| AN-4729 | Replacement Filter Sponge - For 600 / 800 / 1000 Pond Pumps - Ref #247 / 24 | $ 6.50 | | | AN-M290SP1 | Replacement Casing - For 300 / 400 / 500 Pond Pumps - Ref #290 / 291 / 292 | $ 8.50 | | | AN-M247SP1 | Replacement Casing - For 600 / 800 / 1000 Pond Pumps - Ref #247 / 248 / 249 | $ 13.50 | | | AN-M277SP1 | Replacement Casing - For 1500 / 2000 / 2500 Pond Pumps - Ref #277 / 278 / 2 | $ 17.00 | | | AN-M290SP2 | Replacement Fountain Set - For 300 / 400 / 500 Pond Pumps - Ref #290 / 291 | $ 13.00 | | | AN-M247SP2 | Replacement Fountain Set - For 600 / 800 / 1000 Pond Pumps - Ref #247 / 248 | $ 19.00 | | | AN-M277SP2 | Replacement Fountain Set - For 1500 / 2000 / 2500 Pond Pumps - Ref #277 / 2 | $ 27.50 | |
|
|
|
