Aqua UV - Classic and Wiper - Ultraviolet Sterilizers

As a sterilizer: Maximum flow rate: 642 GPH. 5-200 Gallons size.

As a clarifier: Maximum flow rate: 1000 GPH. 5-1500 Gallons size which may require 50% to 75% plant coverage.

• Water flow rates are based on end of lamp life at 14 months.
• 1 LAMP.
• Unit: 16" X 4-1/2" X 2-1/2".
• 7 LBS

Unit Includes Lamp, Sleeve and Transformer

As a sterilizer: Maximum flow rate: 700 GPH. 200-500 Gallons size.

As a clarifier: Maximum flow rate: 1800 GPH, up to 2000 Gallons size which may require 50% to 75% plant coverage.

• Water flow rates are based on end of lamp life at 14 months.
• 1 LAMP.
• Unit: 16" X 4-1/2" X 2-1/2"
• 3/4" Barbed or 2" In and Out
• 7 LBS

Unit Includes Lamp, Sleeve and Transformer

As a sterilizer: Maximum flow rate: 1200 GPH. 500-1200 Gallons size.

As a clarifier: Maximum flow rate: 2000 GPH, up to 4000 Gallons size which may require 50% to 75% plant coverage.

• Water flow rates are based on end of lamp life at 14 months.
• 3/4" or 2" INLET/OUTLET
• 1 LAMP.
• Unit: 20" X 4-1/2" X 2-1/2".
•  7 LBS

Includes Lamp, Sleeve and Transformer

As a sterilizer: Maximum flow rate: 2900 GPH. 1200-2000 Gallons size.

As a clarifier: Maximum flow rate: 3000 GPH, up to 6000 Gallons size which may require 50% to 75% plant coverage.

• Water flow rates are based on end of lamp life at 14 months.
• 3/4" Barbed or 2" INLET/OUTLET
• 1 LAMP.
• Unit: 37-3/8" X 4-1/2" X 2-1/2".
• 10LBS

Includes Lamp, Sleeve and Transformer

As a sterilizer: Maximum flow rate: 3200GPH. 1500-3000 Gallons size.

As a clarifier: Maximum flow rate: 3500 GPH, up to 6000 Gallons size which may require 50% to 75% plant coverage.

• Water folw rates are based on end of lamp life at 14 months.
• 3/4" Barbed or  2" INLET/OUTLET
• 1 LAMP.
• Unit: 20"X 4-1/2" X 2-1/2".
• 9 LBS

Includes Lamp, Sleeve and Transformer

As a sterilizer: Maximum flow rate: 3678 GPH. 2200-4400 Gallons size.

As a clarifier: Maximum flow rate: 4000 GPH, up to 7000 Gallons size which may require 50% to 75% plant coverage.

• Water folw rates are based on end of lamp life at 14 months.
• 2" Inlet/Outlet
• 2 LAMPS.
• Unit: 37-3/8" X 10-3/8" X 2 1/2"

Includes Lamps, Sleeves and Nema Rated Transformer

As a sterilizer: Maximum flow rate: 4080 GPH. 4400-6000 Gallons size.

As a clarifier: Maximum flow rate: 6500 GPH, up to 12000 Gallons size which may require 50% to 75% plant coverage.

• Water flow rates are based on end of lamp life at 14 months.
• 2" Inlet/Outlet
• 3 LAMPS.
• Unit: 37-3/8" X 15-1/2" X 2 1/2".
• 29 LBS.

Includes Lamps, Sleeves and Nema Rated Transformer

As a sterilizer: Maximum flow rate: 5400 GPH. 6000-8500 Gallons size.

As a clarifier: Maximum flow rate: 9000 GPH, up to 12000 Gallons size which may require 50% to 75% plant coverage.

• Water flow rates are based on end of lamp life at 14 months.
• 2" INLET/OUTLET
• 4 LAMPS.
• Unit: 37-3/8" X 14-3/4" X 8".
• 26 LBS

Includes Lamp, Sleeves and Nema Rated Transformer

As a sterilizer: Maximum flow rate: 6600 GPH. 8500-13000 Gallons size.

As a clarifier: Maximum flow rate: 10000 GPH, up to 20000 Gallons size which may require 50% to 75% plant coverage.

• Water flow rates are based on end of lamp life at 14 months.
• 2" INLET/OUTLET
• 5 LAMPS.
• Unit: 37-3/8" X 15" X 13".
• 42 LBS

Includes Lamp, Sleeves and Nema Rated Transformer

As a sterilizer: Maximum flow rate: 7200 GPH. 13000-17000 Gallons size.

As a clarifier: Maximum flow rate: 12000 GPH, up to 25000 Gallons size which may require 50% to 75% plant coverage.

• Water flow rates are based on end of lamp life at 14 months.
• 2" INLET/OUTLET
• 6 LAMPS.
• Unit: 37-3/8" X 19-5/8" X 2 1/2".
• 55 LBS

Includes Lamps, Sleeves and Nema Rated Transformer
